Features
- Diverter Integrated into flow control handle
- Lever/Handle Temperature control handle, Flow control handle
- Mechanical parts Ceramic head part for flow control, Thermostatic cartridge for automatic temperature control, Non-return valve(s), Litter filter(s)
- Number of spray functions 1 spray function
- Shower parts Hand shower, Shower rail, Overhead shower, Adjustable shower rail bracket, Shower hose (1750 mm), Variable fixing points, Rotatable ball joint connection, Anti limescale technology (easy to clean)
- Advanced features Flexible length / can be shortened
- Color Chrome
- Temperature Safety stop against scalding at 38°C, The housing of the fittings conducts minimal heat
Flow attributes
- Flow-rate at 300 kPa 0.25 / 0.26 l/s
- Pressure loss with flow (0.2 l/s) 180 kPa
Technical properties
- Backflow prevention (EN1717) EB
- Connection size G3/4
- DN-size (nominal dimension) DN15
- Hot water supply max. +65°C
- Installation width 40 mm
- Material Brass
- Projection 434 - 459 mm
- Working pressure 100 - 1000 kPa
Regulations
- EN standard EN 1111, EN 1112, EN 1113
- Noise class I (ISO 3822)
Approvals and Declarations
- KIWA SE 1664
+44350130+7402-33.webp)
SP7401 Shower system
Ask pricing from your local retailers.
| Spare parts | Code | Spare part guide | ||
| 01 |
|
Flow control handle (Chrome) |
|
|
| 02 |
|
Diverter and cartridge |
|
Download |
| 03 |
|
Combiner |
|
|
| 04 |
|
Filter sealing, G3/4, DN20 |
|
|
| 05 |
|
Thermostatic cartridge |
|
Download |
| 06 |
|
Temperature control handle (Chrome) |
|
|
| 07 |
|
Slide for shower rail (Chrome) |
|
Download |
| 08 |
|
Shower pipe holder (Chrome) |
|
Download |
