Variants
5611FZ | Washbasin faucet, 3 V, Bluetooth

Oras Clinica Hybrid

EAN code
6414150101960
Active markets
FIN, SWE, NOR, POL, EST, LVA, LTU

Clinica Hybrid series is giving you a whole new modern design to fit into any bathroom. The long loop lever gives you easy and intuitive operation and with our intelligent touchless functions build into same faucet it also supports hygiene operation without any touch needed.

Key Features
Aerator with laminar flow
Newest Sensor technology for better detection and operation comfort
Bluetooth technology for easy adjustment to personalize settings
Antiscalding protection for Sensor usage

Find local retailer
Features
  • Aerator Laminar stream
  • Connection Flexible inlet pipes
  • Electronic parts Advanced PSD sensor, Solenoid valve, Power supply
  • Lever/Handle Long shape
  • Mechanical parts ø 40 mm ceramic cartridge for flow and temperature control
  • Advanced features Inner body made of DZR brass, Waterways without nickel coating, 3S-installation system for safe and simple mounting
  • Spout Fixed spout
  • Color Chrome
  • Temperature Limitation option for maximum temperature and flow-rate
Software settings
  • Afterflow period 3 s (1-20 s)
  • Automatic flush off (off/1-120 h)
  • Automatic flush period 30 s (1-1800 s)
  • Max. flow period 10 s (1 - 1800 s)
Flow attributes
  • Flow-rate at 300 kPa 0.09 l/s
  • Pressure loss with flow (0.1 l/s) 300 kPa
Technical properties
  • Backflow prevention (EN1717) EB
  • Connection size G3/8
  • DN-size (nominal dimension) DN6
  • Hot water supply max. +70°C
  • Material Brass
  • Projection 115 mm
  • Working pressure 50 - 1000 kPa
Electronics
  • Battery AA 1.5 V Lithium x 2
  • Bluetooth version 5.x (D060576)
  • Electrical Connection 9 V
Regulations
  • EU Directives Radio Equipment Directive 2014/53/EU , Low Voltage Directive 2014/35/EU , EMC Directive 2014/30/EU , RoHS Directive 2011/65/EU
  • EN standard EN 817, EN 15091, ETSI EN 301 489-1 V1.9.2 , ETSI EN 300 328 v2.2.2 , EN 61000-6-1:2007 , EN 61000-6-3:2007+A1:2011+AC:2012 , EN 60335-1:2012+A11+A13+A1+A14+A2+A15:2021, Part 19.11.4
  • Noise class I (ISO 3822)
  • Protection class IP 55
Approvals and Declarations
  • STF EUFI29-23004174-TH
