Variants
2639AF-33 | Kitchen faucet with dishwasher valve, 9 V
Find local retailer
Oras Optima
The Oras Optima is the perfect fit for any kitchen, with a proven expert quality you can rely on, no matter your specific needs. Durable and long-lasting in both design and service life, this faucet brings you joy and confidence for years to come. Functional considerations and a dedicated level of detail offer a new user experience.
Features
- Aerator Standard aerator
- Connection Flexible inlet pipes
- Dishwasher valve Remote controlled stop valve for external equipment
- Electronic parts Solenoid valve, Power supply
- Lever/Handle Single operating lever/handle, Pin shape, Hot/Cold symbols
- Mechanical parts ø 30 mm ceramic eco cartridge for flow and temperature control
- Advanced features Inner body made of DZR brass, Software settings adjustable via App
- Spout Swivel spout
- Color Matt black
- Temperature Limitation option for maximum temperature and flow-rate
Software settings
- Dishwasher valve open period 4 h / 12 h
Flow attributes
- Flow-rate at 300 kPa (with flow controller) 0.18 l/s
- Pressure loss with flow (0.2 l/s) 375 kPa
Technical properties
- Backflow prevention (EN1717) EB
- Connection size G3/8
- Hot water supply max. +70°C
- Material Brass
- Projection 247 mm
- Working pressure 50 - 1000 kPa
Electronics
- Battery CR 2450 3 V
- Bluetooth version 5.x (D060577)
- Electrical Connection 230 / 9 V
Regulations
- EU Directives Radio Equipment Directive 2014/53/EU , Low Voltage Directive 2014/35/EU , EMC Directive 2014/30/EU , RoHS Directive 2011/65/EU
- EN standard ETSI EN 301 489-1 V1.9.2 , ETSI EN 300 328 v2.2.2 , EN 61000-6-1:2007 , EN 61000-6-3:2007+A1:2011+AC:2012 , EN 60335-1:2012+A11+A13+A1+A14+A2+A15:2021, Part 19.11.4
- Noise class I (ISO 3822)
- Protection class IP 54 / transformer IP 20
SP2639AF-33 Kitchen faucet with dishwasher valve
Ask pricing from your local retailers.
Spare parts | Code | Spare part guide | ||
01 |
|
Aerator, STD M22x1 CC A (Matt black) |
|
|
02 |
|
Spout overturning stopper, 60°/0° |
|
Download |
02 |
|
Spout overturning stopper, 60°/0° |
|
Download |
02 |
|
Spout overturning stopper, 120° |
|
Download |
03 |
|
Sealing kit for spout |
|
|
04 |
|
Cartridge, 3.0 |
|
Download |
05 |
|
Tightening nut, M34x1.5 |
|
|
06 |
|
Lever (Matt black) |
|
|
07 |
|
Supporting plate, 100x60mm |
|
|
08 |
|
Fixing set |
|
|
09 |
|
Control unit, 9 V, Bluetooth |
|
|
10 |
|
Battery, CR2450 3 V Lithium |
|
Download |
11 |
|
Pilot valve, 3 V |
|
Download |
12 |
|
Membrane for solenoid valve |
|
Download |
13 |
|
Gasket, 18.5/12x2 EPD |
|
|
14 |
|
Litter filters |
|
|
15 |
|
Power supply, 230/9 V, 550 mA |
|
