2734F | Kitchen faucet with dishwasher valve, 6 V

Oras Optima

Will be discontinued 03/2024
EAN code
6414150070020
Active markets
FIN, SWE, NOR, POL, EST, LVA, LTU
Replacement product
2734FHN

Kitchen faucet with an easy-grip lever, high swivel spout, aerator and smart dishwasher valve. Spout’s swing angle is factory preset at 120° (can be limited to 0° or 60°). Dishwasher valve closes automatically after 4 or 12 hours (one push opens the valve for 4 hours, pushing for 5 seconds opens the valve for 12 hours). Battery operated, 6 V.
F = with flexible pipes

Find local retailer
Features
  • Aerator Standard aerator
  • Connection Flexible inlet pipes
  • Dishwasher valve Electronic stop valve for external equipment
  • Electronic parts Solenoid valve, Light indicated function(s), Low battery indicator
  • Lever/Handle Easy-Grip surface, Single operating lever/handle, Hot/Cold symbols
  • Mechanical parts Litter filter(s), ø 40 mm ceramic cartridge for flow and temperature control
  • Advanced features Inner body made of DZR brass, Surfaces in contact with drinking water contain less than 0.3% lead, Waterways without nickel coating
  • Spout Swivel spout, Swivel range limiting option
  • Color Chrome
  • Temperature Limitation option for maximum temperature and flow-rate
Software settings
  • Dishwasher valve open period 4 h / 12 h
Flow attributes
  • Flow-rate at 300 kPa 0.2 l/s
  • Pressure loss with flow (0.2 l/s) 300 kPa
Technical properties
  • Backflow prevention (EN1717) AA
  • Connection size G3/8
  • Hot water supply max. +70°C
  • Material Brass/Plastic
  • Projection 217 mm
  • Working pressure 50 - 1000 kPa
Electronics
  • Battery Lithium 2CR5 6 V
Regulations
  • EU Directives EMC Directive 2014/30/EU , RoHS Directive 2011/65/EU
  • EN standard EN 817, ETSI EN 301 489-1 V1.9.2 , ETSI EN 300 328 v2.2.2 , EN 61000-6-1:2007 , EN 61000-6-3:2007+A1:2011+AC:2012 , EN 60335-1:2012+A11+A13+A1+A14+A2+A15:2021, Part 19.11.4
  • Noise class I (ISO 3822)
  • Protection class IP 55
Approvals and Declarations
  • Sintef Sintef Nr. 3084
  • STF EUFI29-20002662-TH1
  • KIWA SE 1462
  • UN38.3 UN38-3 Maxell 2CR5
